M-15 PALM KERNEL PRESS
  • Overview
  • Specs & Features
  • Gallery

Specially designed to crush palm kernels to extract oil and to get palm kernel cakes.


Model M-15
Weight Approx. 4085 kgs
Overall Dimensions L:3375 mm   W:1300 mm   H:1490 mm
Capacity 18-20 mt of palm kernels per day (24 hrs)
Gear Reducer 3-phase reduction
Electric Motor 75 hp (6 pole)
Features - High quality cast steel housing to withstand vibration and milled machine base for precise leveling of gearbox and housing mounting

- Pressing worms and collars are welded with hard facing electrodes

- Heavy duty design for longer life span
